Titanium Welded Tube: Precision Engineering & Customized Solutions
Txuj: ASTM B 862
Khoom siv: Gr1, Gr2, Gr3, Gr7, Gr12
Nqe: $25usd/kg-$40usd/kg
Hom: Welded
Puab: Round
Sab nraud txoj kab uas hla: 3-114mm los yog raws li kev cai
Phab ntsa Thickness: 0.5-7mm los yog raws li kev cai
Ntev: Max 12000mm
Nto: Bright
MOQ: 10kgs
Factory Thaj Chaw: 3000 ㎡
Cov neeg ua haujlwm hauv tuam txhab: 48
Pab neeg ua haujlwm pabcuam kev lag luam txawv teb chaws: 20
Tuam Tshoj tus kws tshaj lij titanium raj chaw tsim tshuaj paus
Titanium Welded Tube: Precision Engineering & Customized Solutions
1. Khoom siv & Cov txheej txheem tsim khoom
Qib khoomGR1, GR2, GR3, GR5, GR7, GR12 (ASTM B862 ua raws)
Vuam Technology: TIG (Tungsten Inert Gas) vuam nrogargon gas shieldingUa kom tsawg kawg oxidation thiab siab weld kev ncaj ncees.
Qhov tseem ceeb Advantage: Tsis zoo li cov raj seamless, welded raj tshem tawm cov khoom pov tseg los ntawm extrusion, txo cov nqi tsim khoom los ntawm 20-30% thaum tswj cov khoom siv kho tshuab.
2. Core Technical Advantages
|
Parameter |
Specification |
Kev sib tw Edge |
|---|---|---|
|
OD Ntau |
3-114 hli (Customizable) |
Cov kab uas hla loj dua seamless raj |
|
Phab ntsa Thickness |
0.5-7 hli (± 12.5% kam rau ua) |
Tighter tolerances vs. cov qauv kev lag luam |
|
Ntev |
Txog li 12 m (los yog txiav - mus rau - loj) |
Txo cov khoom pov tseg rau CNC tej yaam num |
|
Nto tiav |
Polished (Ra Tsawg dua lossis sib npaug li 0.8 μm) / Pickled |
Txhim kho corrosion kuj nyob rau hauv ib puag ncig chloride |
|
Nyhav ib Meter |
0.3-1.8kg / m (GR2) |
15% sib dua li 316L stainless hlau |
3. Muaj peev xwm kho tau
Loj Flexibility:
- Txoj kab uas hla: 3–114 mm (tsis yog- qhov ntau thiab tsawg muaj nyob ntawm qhov xav tau).
- Thickness: 0.5-7 mm (hloov tau rau siab -siab lossis lub teeb yuag).
Khoom siv Customization:
- Ntshiab titanium (GR1 / GR2) lossis qib alloyed (GR5, GR7) rau cov tshuaj tiv thaiv tshwj xeeb.
Kev kho saum npoo:
- Mechanical Polishing: Ua tiav daim iav-zoo li ua tiav rau cov ntawv thov kev nyiam huv.
- Tshuaj Pickling: Tshem tawm cov oxides saum npoo kom txhim kho weldability.
4. Kev ruaj ntseg zoo
Kev tshuaj xyuas Weld: 100% eddy kev kuaj tam sim no(ET) rau weld kev ncaj ncees.
Mechanical Testing:
- Tensile zog Ntau dua los yog sib npaug rau 345 MPa (ASTM B862).
- Flattening xeem rau ASTM B348.
Cov ntawv pov thawjDaim ntawv no: ISO 9001, API 5CT, CE Marking.
5. Nqi Efficiency & Sustainability
Kev txuag khoom: welded raj siv 30% tsawg titanium piv rau seamless manufacturing.
Kev rov ua dua tshiab: 100% recyclable, ua raws li kev lag luam ncig.
Lub Sijhawm Lead: 20-25% xa khoom sai dua vim yog kev tsim khoom yooj yim.
Cov duab ntxaws:
